Topic 1: Probabilistic Clock Synchronization¶

@article{cristian1989probabilistic,
  title={Probabilistic clock synchronization},
  author={Cristian, Flaviu},
  journal={Distributed computing},
  volume={3},
  number={3},
  pages={146--158},
  year={1989},
  publisher={Springer}
}

Theorem

Regard all \(H\) as \(C\).

If the clocks of processes \(P\) and \(Q\) are correct, the value displayed by \(Q\)'s clock when \(P\) receives the ("time = ", \(T\)) message (\(C_Q(t_3)\)) is in the interval \([T+min\cdot(1-\rho), T+2D(1+2\rho)-min\cdot(1+\rho)]\).

Extra definition:

• \(2D = C_P(t_3) - C_P(t_1)\), refers to the P's reading version of \(2d\)
• \(T := C_Q(t_2)\)

Proof

\[ \begin{aligned} \because\; & C_Q(t_3) = C_Q(t_2 + min + \beta) \\ \therefore\; & C_Q(t_2) + (min + \beta)(1 - \rho) \leq C_Q(t_3) \leq C_Q(t_2) + (min + \beta)(1 + \rho) \\ i.e.\; & T + (min + \beta)(1 - \rho) \leq C_Q(t_3) \leq T + (min + \beta)(1 + \rho) \\ \because\; & min + \beta = 2d - (min+\alpha) = 2d - min - \alpha \leq 2d - min \\ \because\; & 2D(1 - \rho) \leq 2d \leq 2D(1 + \rho) \\ \therefore\; & min + \beta \leq 2D(1 + \rho) - min \\ \because\; & \beta \geq 0 \\ \therefore\; & T + min(1 - \rho) \leq C_Q(t_3) \leq T + 2D(1 + 2\rho) - min(1 + \rho) \\ i.e.\; & C_Q(t_3) \in [T + min(1 - \rho), T + 2D(1 + 2\rho) - min(1 + \rho)] \end{aligned} \]

This is the smallest interval which \(P\) can determine in terms of \(T\) and \(D\) that covers \(Q\)'s clock value.

Thus, in order to minimize the maximum error, \(P\) choose the midpoint of this interval as the estimate of \(Q\)'s clock value at \(t_3\):

And define the maximum error \(e\) (radius of the interval) as:

in order to control the precision of the synchronization, we define a boundary condition for the maximum error \(\varepsilon\), it discards any reading attempt for which it measures an actual round trip delay greater than \(2U\) (while the actual error is \(e\) and the reading round trip delay is denoted as \(2D\)).

Another constrains is \(U \geq U_{min} = (1+\rho)min\) for handling the drifting issues.

Given this, we have a judgment: for the timeout delay, closer to \(U_{min}\): more precise but higher failure rate, vice versa.

A best reading precision achievable by a clock reading experiment is: \(e_{min} = 3\rho\cdot min\)

Define the reading attempt failure probability as \(p\). If a reading attempt fails, we give a retry after a fixed delay \(W\) for a maximum of \(k\) times. Then the overall success probability is \(1 - p^k\). Since each attempt costs two messages, the average number of messages \(\bar{n}\) for achieving rapport is \(\bar{n} = \frac{2}{1-p}\).

Define \(H(t)\) as the hardware clock time which is not adjustable, and \(C(t)\) is the logical clock time which will be read, and a periodically computed adjustment function \(A\):

Here \(m\) and \(N\) are computed periodically.
